Ethernet Switch
8 Port Ethernet Switch 24VAC/DC
£152.00
8 Port 10/100 Mbs Ethernet Switch – 1 Fast ethernet fibre/RJ45 optional port, 4 x 10/100 Base t(x) ports
⚡ Electrical Calculator
🔌 Cable Size Reference
🌬 Unit Converter
🔋 Transformer VA & MCB Calculator
📊 Reference Guide
| Current (A) | Cable Size (mm²) |
|---|---|
| 6 | 1 |
| 6-12 | 1.5 |
| 12-25 | 2.5 |
| 25-32 | 4 |
| 32-40 | 6 |
| 40-64 | 10 |
| You must consider Ambient Temperature, Location and Thermal insulation in contact with cable. | |
Description
- 8 Port 10/100 Mbs Ethernet Switch
- 1 Fast ethernet fibre/RJ45 optional port, 4 x 10/100 Base t(x) ports
- Redundant dual power inputs: 12-48VDC/18-30VAC
- Din Rail Mount
- Industrial temperature range
- Metal Housing
Product Code: IES-0008T
UKCA Declaration: IES-0008T-UKCA
Specification
| Voltage | 12-48VAC/18-30VAC |
|---|---|
| Operating Temperature | -10°C to +60°C |
| Approvals | UL508, Class I Div 2, ATEX Zone 2, IECEx, CE, FCC |
| Ingress Protection (IP Rating) | IP30 |
| Data Transmission Speed | 10/100 Mbps |
| Ethernet Port | 5 x RJ45 |
| Housing | IP30 Metal Housing |
| Manufacturer/Brand | Kyland |
Additional information
| Types |
CSW-NO-ASD, CSW-NO-ASD2, CSW-NO-ASP, CSW-NO-ASP2, CSW-NO-FSD, CSW-NO-FSP |
|---|
