Flamefast Gas Detector (FGD)

£182.00

The Flamefast Gas Detector is a cost-effective gas-sensing solution that interfaces with the Flamefast range of Gas Safety Systems via the BACnet MS/TP protocol. The bold traffic light LCD and built-in audible alarm provide a clear indication of any issues local to the sensor.

- +

⚡ Electrical Calculator

🔌 Cable Size Reference

🌬 Unit Converter

🔋 Transformer VA & MCB Calculator

📊 Reference Guide

You must consider the following: Ambient Temperature, Location and Thermal insulation in contact with cable.
Current (A) Cable Size (mm²)
12 1
16 1.5
20-25 2.5
25-32 4
32-40 6
40-64 10
SKU: FGD Categories: , Tags: , , , , Brand: ,

The Flamefast Gas Detector is a cost-effective gas-sensing solution that interfaces with the Flamefast range of Gas Safety Systems via the BACnet MS/TP protocol.
The bold traffic light LCD and built-in audible alarm provide a clear indication of any issues local to the sensor.

Top Key Features

  • 24V AC/DC Power Supply
  • Pre-calibrated
  • Traffic light LCD readout
  • BACnet MS/TP over RS485
  • Simple configuration and calibration
  • UK MANUFACTURED

Overview

Although the sensors can be connected to third-party BACnet networks, for safety systems, it is strongly recommended that they be used in conjunction with a Flamefast BoilerGuard or GasMonitor.

The broadband Pellistor and Infra-red Hydro-carbon sensors can be calibrated to suit most combustible gases, with the option to factory calibrate and rename the sensor for the specific gas. Flamefast can also offer a full range of toxic gas sensors, including H2S, HCN and many more (please contact for details).

Key Features

  • 24V AC/DC Power Supply
  • Pre-calibrated
  • Traffic light LCD readout
  • BACnet MS/TP over RS485
  • Simple configuration and calibration
  • Calibration and ‘End of Life’ reminders
  • Oxygen Sensors monitor Enrichment and depletion as standard
  • Mounts onto any standard single-gang junction box or conduit box
  • UK MANUFACTURED

Dimensions

Height: 125 mm
Width: 86 mm
Depth: 36 mm

Technical Specifications

Power Supply: 24V AC/DC ± 10%
Power Consumption: 60mA
BACnet: MS/TP over RS485
Baud: 9k6, 19k2, 38k4 or 76k8
127 Address (1/10th Load)
Full specification available on request
Audible: 60dB @ 30cm
Operation Conditions:
Temp 5-40°C
Humidity 0-95% (NC)
Sampling Method: Diffusion
Warm-up Time: 60 Seconds (24 Hours for full stability)
Response Time (T90): < 60 Seconds (Adjustable)
IP Rating: IP40
Housing Material: PC/ABS
Colour: Pure White (RAL9010)
Approval: CE, UKCA

Installer Selectable Options

Audible Alarm Enable/Disable
Auto Zero Calibration Enable/Disable

Part Numbers & Options / Accessories

Part No Gas Range Typical Life (years)
FGD-NG Natural Gas (Methane) 100% LEL 5
FGD-LPG Propane 100% LEL 5
FGD-H2 Hydrogen (LEL) 100% LEL 5
FGD-HC Hydrocarbon (Pellistor) 100% LEL 5
FGD-IRHC Hydrocarbon (Infra-red) 100% LEL 5
FGD-SF6 Sulfur Hexafluoride 1,000ppm 5
FGD-CO2 Carbon Dioxide 5% 5
FGD-CO Carbon Monoxide (Plant/Carpark) 200ppm 5
FGD-NO2 Nitrogen Dioxide 5ppm 3
FGD-NH3 Ammonia 100ppm 3
FGD-CL2 Chlorine 5ppm 3
FGD-H2e Hydrogen (Electrochemical) 2,000ppm 3
FGD-SO2 Sulphur Dioxide 5ppm 3
FGD-O2 Oxygen 25% 5

HVACProducts.co.uk

Data Sheets

General specifications in .pdf format FGD_DS_0223

Operation Manuals

Installation and Operation instructions in .pdf format FGX_OM_0224

Weight 0.20 kg
Dimensions 12.5 × 8.6 × 3.6 cm
