iSMA-B-FCU-HH

This fan coil controller is designed to remove the current frustration with available products. It has everything from ease of use to flexibility and price. Here are the top 6 reasons you would choose this Fan Coil Controller for your next project.

1. It comes pre-loaded with software templates covering over 95% of requirements. And even if you have to make changes, they are minimal.
2. It is fully programmable with our SMA Tool, and you do not need any previous experience or specialised training.
3. It has the most generous IO: 4 Universal / Special Inputs, 4 Digital Inputs, 3 Analogue Outputs, three fan speed relays, a relay for the electric heater, a relay for the electric cooler, 2 Triac Outputs for the heating and cooling valves
4. It supports a wide range of Universal input sensors, and by default, it can read any 10K3 sensor.
5. It has a built-in 24 Volt transformer, which can power most actuator valves in the market.
6. It has two communication ports:

• One to be used with any Modus or BACnet BMS Controller
• And the second one to be used with any Modbus Display

iSMA-B-FCU_Hardware_Manual_DMP242en_V1.6
