Description
A range of Level Switches designed for high and low liquid level detection in tanks and vessels. Units consist of a lever-arm reed-switch assembly and a tank-fixing assembly. Units fit from the inside of the tank and tighten onto a back nut and are available for top or side mounting..
Specification
Contact Form: Reversible float
Switching Voltage Max. V: 125Vac break down 250Vac
Switching Current Max. A: 0.5
Carry Current Max. A: 1.0
Switching Capacity Max. VA: 10W SPST
Contact Resistance Max. mOhms: 200
Lead Wire: UL 1007 AWG22 PVC
Operating Pressure Max. Kg/cm²: 1.0
Operating Temperature Deg.˚C: -20˚C…+80˚C
Material: Polypropylene
Suitable Specific Gravity: 0.8
Mounting Hole Diameter: 10mm
Additional information
| Weight | 0.7 kg |
|---|---|
| Dimensions | 9.7 × 7.9 × 6.5 cm |
