AB-QM PICV, Danfoss
DN40 Tailpiece for ABQM
£24.00
Tailpiece with External thread DN 40
⚡ Electrical Calculator
🔌 Cable Size Reference
🌬 Unit Converter
🔋 Transformer VA & MCB Calculator
📊 Reference Guide
| Current (A) | Cable Size (mm²) |
|---|---|
| 6 | 1 |
| 6-12 | 1.5 |
| 12-25 | 2.5 |
| 25-32 | 4 |
| 32-40 | 6 |
| 40-64 | 10 |
| You must consider Ambient Temperature, Location and Thermal insulation in contact with cable. | |
Description
Tailpiece with External thread DN 40
| Gross weight | 0.394 Kilogram |
| Net weight | 0.38 Kilogram |
| Volume | 0.547 Liter |
| EAN | 5702421561607 |
| Type | AB-QM accessories |
| Product group | Pressure-independent balancing and control valves |
| Connection to the pipe | R 1 ½ |
| Connection to the valve | DN 40 |
| Contains batteries | No |
| Description | Tailpiece with External thread DN 40 |
| EU RoHS compliance | Yes with exemptions |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| SCIP dossier no. | b1c30c39-2a01-4a7e-aa0f-69a47ec00790 |
| SCIP dossier product name | Tail pieces with thread |
| Usage | AB-QM |
Additional information
| Weight | 0.4 kg |
|---|
